24 to 48 VDC ± 20%
Power requirement: 8 Watt max.
2 pin screw terminal connector
10/100Mbps auto,
RJ-45 connetor with integrated Link & Activity LEDs
Protocols: TCP/IP, UDP, RTP, DHCP, Multicast capable
DB9 female socket
Optionale XLR Cable Set
Differential input, 18kOhm input impedance
Clipping level 15dBu, 12.3 Vpp
Frequency response (-3dB) 20..20’000 Hz**
Signal to Noise Ratio 87 dB, THD 0.01%
Stereo crosstalk -88 dB
Input level software controllable (-3.. +19.5dB)
Differential output, 40..60 Ohm output impedance
Output level software controllable
Full scale output voltage: 15dBu, 12.3 Vpp
Frequency response (-3dB) 20..20’000 Hz**
Signal to Noise Ratio 92dB, THD 0.03%
Stereo crosstalk -66 dB
4 pin screw terminal connector
300..230’400 Baud asynchronous, 7/8 bit
Male 9-pin Sub-D connector
.230‘400 Baud asynchron., tunneling or local control
12 VDC supply output for external device (100 mA max.)
Encoding and decoding MP3 in variable and constant bit rate
( VBR/CBR*, 8kbps..320kbps) at 8..48kHz sample frequency
PCM (L16, uLaw, aLaw) at 8..48kHz sample frequency
Decoding AAC+* (AAC-LC, HE-AAC, HE-AAC v2)
Two 6 pin screw terminal connectors
4 contact closure sensing inputs
4 relay contacts, 24V 0.5A, normally open
Aluminum case, 620g, rack mountable using accessory bracket
216x38x125mm (8.5×1.5×4.92 inch)
According MIL217F at 25°C
Exstreamer 500 min. 410 000h
* Exstreamer 500 Hardware revision 2 only
** depends on used codec, best results @48kHz PCM
